Specification
Size & Weight
| MAIN UNIT SIZE – BODY ONLY (W X H X D) | 900 x 64 x 90 mm |
| MAIN UNIT WEIGHT – BODY ONLY | 3.0 kg |
| SUBWOOFER SIZE (W X H X D) | 207 x 402 x 330 mm |
| SUBWOOFER WEIGHT | 9.0 kg |
| Rear Speaker Size (W x H x D) | 91 x 216 x 91 mm |
| Rear Speaker Weight | 1.0 kg |
Amplifier
| Amplifier Type | Digital Amplifier, S-Master |
| Amplifier Channels | 5.1ch |
| Power Output (Total) | 1000 W |
| POWER OUTPUT (FRONT) | 152 W+152 W |
| POWER OUTPUT (CENTRE) | 152 W |
| POWER OUTPUT (SUBWOOFER) | 240 W |
| POWER OUTPUT (REAR) | 152 W+152 W |
Subwoofer
| Subwoofer type | Wired |
Interface
| Input and output terminals | Optical-audio input, Analogue audio input (stereo mini), USB type A |
| Bluetooth® | Yes |
| Bluetooth® version | ver. 1.3 |
HDMI
| Number of Input/Output | 0/1 (ARC) |
| BRAVIA® Sync | Yes |
| HDMI CEC | Yes |
Audio formats
| Optical Input | Dolby® Digital, Dolby® Dual mono, DTS®, LPCM |
| USB | Wav, mp3, WMA |
| Bluetooth® (Receiver) | AAC SBC |
Sound Function
| Sound Mode | Auto Sound, Cinema, Music, Standard |
| Sound Effect | Night Mode, Voice Mode |
Application
| Sony | Music Center (Bluetooth® Connection) | Yes |
Details
| Power Consumption | 140 W |
| Power consumption(on QuickStart mode) | less than 0.5 W (Bluetooth® standby off) |
